Specifications
Electrical
| Rated Power | 2.86 kW |
|---|---|
| Input Voltage | 220 VAC ± 20% |
| Rated Input Frequency | 50/60 ±3 Hz |
| Metrology Testing | Onboard |
| Output Voltage | 220 VAC ± 20% |
| Rated Output Current | 13 A |
| Standby Power Consumption | ≤4.3 W |
| Man-Machine Interaction | Status indicator; button; current indicator |
Function
| Startup Method | APP charging, plug and play |
|---|---|
| Status Indicator Light | Blue flashing: Charging Blue: Reserved Red flashing: Fault Yellow: Upgrading Green flashing: Charging stopped Green: Available |
| Bluetooth | Yes |
| Auto Timing | Yes |
| Update | Bluetooth |
Basic
| Types of Protection | Protects against overvoltage, undervoltage, short circuit, overcurrent, overtemperature, relay adhesion,surge, leakage, overfrequency, underfrequency,lightning and CP disconnection . It can also support grounding protection. |
|---|---|
| Cooling Method | Self-cooling method |
| Measurement Accuracy | Level 1 |
Structure
| Casing Material | UL94-V0 rated PC |
|---|---|
| Product Dimensions | 97 mm × 200 mm × 56 mm (3.82" × 7.87" × 2.20") (W × H × D) |
| Packaging Dimensions | 393 mm × 116 mm × 280 mm (15.48" × 4.57" × 10.91") (W × H × D) |
| Net Weight | 1.82 kg (4.01 lb) |
| Gross Weight | 2.54 kg (5.60 lb) |
| Cable Length | 5 m (this includes the connector) |
Environment
| Operating Temperature | –30 °C to +55 °C (– 22 °F to +131 °F) |
|---|---|
| Operating Humidity | 5%–95% (RH), non-condensing |
| Operating Altitude | ≤2,000 m (6,561.68 ft) |
| Vandal-proof Rating | IK08 |
| Protection | IP66 (main controller), IP55 (in coupling status) |
| Noise Control | 55 dB |
Certification
| Certifications | IEC 62196-2; IEC 61851-1 |
|---|
